Honeywell Modutrol IV M72 Series User Manual

7 63-2202—3
M7261,M7272,M7274,M7281,M7282,M7284,M7285,M7286,M7294
INSTALLATION
Fig. 4—Mounting Modutrol IV Motor on Q618 Valve Linkage.
VALVE
LINKAGE
ADAPTER
BRACKET
VALVE
STANDARD
BOLTS
M5776
MOTOR
WIRING BOX
BOLTS PROVIDED (4)
POWER END
OF MOTOR
MOTOR
BOLTS PROVIDED (4)
WIRING BOX
POWER END
OF MOTOR
NON-SPRING
RETURN
SPRING RETURN
1 2
1 #12 OR 1/4'' ZINC PLATED
MACHINE SCREWS OR BOLTS.
2 FASTEN ADAPTER BRACKET TO VALVE
LINKAGE AND HAND TIGHTEN BOLTS.
SECURE MOTOR TO BRACKET USING
FOUR BOLTS (PROVIDED). THEN TIGHTEN
BRACKET-TO-LINKAGE BOLTS.
