PAGE - 8 Installation manual LCD6000
NOTIFIER ITALIA Doc. M-184.1-LCD6000T-ENG Rev A.2 LCD6000_manu
Condition with breakdown zone events
The following is displayed when the control unit is in breakdown zone condition
The breakdown events are also initially displayed for zone
Through the arrows keys you can scroll the breakdown zones
In case of several breakdown zones to display the devices in a specific zone, the zone list must be scrolled
until the chosen zone is in the display area of the first event.
By pressing the key for some seconds you can access the detailed list of the selected zone breakdown
points. you can scroll the failed device list.
Breakdown
zone
Text
prograrmmed for
Failed device
S = sensor
M = module
Programmed text
for the device
TYPE-ID
Breakdown zone
counter
Date and time
of the first
zone
breakdown
event
Date and time of the
latest alarm zone
event
Display area of
the first event
