CN1 Terminal block
No Description Features Notes
7
NOT USED
6
NOT USED
5
LIN –
RS 485 serial line
4 GND
Reference negative for RS 485 serial line
3 LIN +
RS 485 serial line
2 GND
Power supply input
1 + 24Vcc
ELECTRICAL FEATURES
Operating temperature: - 5° C - + 40° C.
Relative humidity: 10 % - 93 % (with no condensation).
Storing temperature: - 10° C - + 50° C.
Weight: Kg 0, 54
Power supply
Power supply = 10 ÷ 30Vcc.
Absorption without anomalies (breakdowns or alarms) with display off : 30 mA
Absorption with anomalies (breakdowns or alarms) with display on and active buzzer : 81 mA
N.B.
In case of local power supply the negatives must be common.
