PAGE - 2 Installation manual LCD6000
NOTIFIER ITALIA Doc. M-184.1-LCD6000T-ENG Rev A.2 LCD6000_manu
This device must be installed and must operate in accordance with these instructions and
with the rules in force in the installation place.
GENERAL DESCRIPTION
DESCRIPTION
LCD-6000T is a panel for the management of gas detection devices or Technological devices having
a 4-20mA interface which are installed in AM-2000; AM-4000; AM-6000 control units.
Up to 16 LCD-6000T can be connected to a single control unit as a terminal function.
The LCD-6000T panel indicates all signallings coming from the 4-200 mA interface modules and allows to
perform the following functions :
EVENT RECOGNITION.
ALARM RESET.
DISPLAY OF EXCLUDED POINTS AND ZONES
DISPLAY OF ZONES AND POINTS UNDER TEST
OPERATION
It needs the local programming to assign the peripheral address
The LCD-6000T panel displays time, date and personalized messages coming from AM series control
units.
On each LCD-6000T control panel, can be independently performed the functions relevant to the keys:
- Buzzer Silencing and Alarm Reset.
- Moreover, it allows to display the event lists subdivided into:
- Alarms, breakdowns, System breakdowns.
Technical specifications:
Microprocessor system
LCD display 320 x 240 points
Keyboard with keys dedicated to specific functions: Buzzer Silencing, Reset.
Serial lines :
- 1 RS 485 interface
Power supply
10 ÷ 30Vcc
Connections
- 2 power supply cables
- 3 cables for serial connection
Mechanical features:
The LDC6000 panel mechanical features are suitable for wall installations.
Sizes 180mm (L) x 168mm (H) x 55mm (P)
Protection grade : IP 20
Operation temperature : from -5 °C to +40 °C
PANEL
LCD-6000-N
LCD-6000-T
LCD-6000A
Max numbers LCD
installable
AM-2000N max 12 max 10 16
AM-4000 max 16 max 14 22
AM-4000G max 16 LCD-6000-T NO 16
AM-6000N max 16 max 16 24
