PAGE - 26 Installation manual LCD6000
NOTIFIER ITALIA Doc. M-184.1-LCD6000T-ENG Rev A.2 LCD6000_manu
Technological ranges.
The Technological Range programming is performed on the control units
From the Programming menu by selecting the item “TECHNOLOGICAL RA NGES” you enter the
programming procedure where it is possible to configure a maximum number of 16 ranges whose first seven
are by default as it is shown in the following table.
N Description (max.10 char.) ABBREVIATION
(max3 char.)
PW4
(µs)
PW4
(µs)
Lowest value of
the scale
Highest value of
the scale
I01 0-100% % 585 2928 0 100
I02 0-200ppm ppm 585 2928 0 200
I03 0-25% % 585 2928 0 25
I04 0-100ppm ppm 585 2928 0 99
I05 0-500ppm ppm 585 2928 0 500
I06 0-20ppm ppm 585 2928 0 20
I07 -10+70ºC ºC 585 2928 -10 +70°C
I08
I09
I10
I11
I12
I13
I14
I15
I16
The Technological Range defines the physical value that the 4-20ma interface module must analyze by
assigning them the lowest values and the highest value of the scale
Programming of the “TECHNOLOGICAL RANGES” (from I08 to I16).
From the Programming menu by selecting the item “TECHNOLOGICAL
RANGES” the programming procedure is accessed.
First folder or Main folder (Progr. of Description, Abbreviation).
Press the key
F1 to display or
change the previous
range
Press the key
F2 to display
or change the
subsequent range
Reading of programmable description (max.10 char.) which
is displayed in the programming phase of the
Technological devices refer to the chapter Third Folder or
option folder
(
(
P
P
r
r
o
o
g
g
r
r
.
.
o
o
f
f
T
T
r
r
a
a
c
c
k
k
i
i
n
n
g
g
a
a
n
n
d
d
L
L
e
e
d
d
B
B
l
l
i
i
n
n
k
k
e
e
t
t
c
c
.
.
.
.
.
.
)
)
Abbreviation of the physical highest value of the
scale
Selected Range
Ranges
configurable
by the user
Pre-set
ranges
