102 | Performance Series IP Camera Software Configuration Guide
General
Power Supply 12 VDC, PoE (802.3af)
Power Consumption HBD1PR1: 4.8 W max. (IR LEDs on)
HBD3PR1: 4.7 W max. (IR LEDs on)
HBD3PR2: 8.5 W max. (IR LEDs on)
Operating Temperature Range
–22°F to 140°F (–30°C to 60°C)
Relative Humidity 10% to 100%, condensing
Ingress Protection Rating IP66
Dimensions HBD1PR1/HBD3PR1: 6.5 × 2.76 in. (165.0 × 70.0 mm)
HBD3PR2: 8.46 × 3.56 in. (214.8 × 90.4 mm)
Weight HBD1PR1/HBD3PR1: 0.84 lb (0.38 kg)
HBD3PR2: 1.43 lb (0.65 kg)
Regulatory FCC: Part 15B Class B
System Compatibility HEN041**(X) H.264 4-Channel 1080p Embedded Network Video Recorder
HEN081**(X) H.264 8-Channel 1080p Embedded Network Video Recorder
HEN161**(X) H.264 16-Channel 1080p Embedded Network Video Recorder
Recommended Accessories HBS2-BB Junction Box
Table B-2 HBD1PR1/HBD3PR1/HBD3PR2 Specifications
