60-2034—7 2
RA890F
SPECIFICATIONS • ORDERING INFORMATION
Specif ications
TRADELINE
®
MODELS
TRADELINE
®
models of this device are available. They
are selected and packaged to provide ease of stocking, ease of
handling, and maximum replacement value. TRADELINE
®
model specifications are the same as those of the standard
model except as noted below.
TRADELINE
®
MODELS AVAILABLE:
RA890F for 120V, 50/60 Hz power supply.
RA890F for 240V, 50/60 Hz power supply.
ADDITIONAL FEATURES: TRADELINE
®
packed with
cross reference label and special cross reference listing.
STANDARD MODELS
MODEL: RA890F Protectorelay™ Primary Control.
ELECTRICAL RATINGS:
Voltage and Frequency: 100V, 120V, 208V, 220V, or
240V, 50/60 Hz. As ordered.
Power Consumption:
60 Hz: 7.0W maximum, 1.7W standby.
50 Hz: 8.5W maximum, 3.0W standby.
VA Ratings:
60 Hz: 13.0 VA maximum, 8.3 VA standby.
50 Hz: 17.0 VA maximum, 13.6 VA standby.
Terminal Ratings:
a
If ignition and motor are connected to terminal 3, termi-
nal 4 cannot be used. This is to prevent overloading
relay 1K.
b
Alternate Rating: 25 VA pilot duty plus one or more
motorized valves with total rating 400 VA opening,
200 VA holding.
Alarm Contacts: 3.0A at 24 Vac or 1.0A at 120 Vac in
suitable wiring enclosure.
Low Voltage Control Circuit (T-T): 0.3A.
Ordering Information
When purchasing replacement and modernization products from your TRADELINE
®
wholesaler or your distributor, refer to the
TRADELINE
®
catalog or price sheets for complete ordering number, or specify:
1. Order number (standard or TRADELINE
®
).
2. Voltage and frequency.
3. Flame response time.
4. Safety switch timing.
5. Alarm contacts, if desired.
6. Fast thermistor timing if desired.
7. Accessories, if desired.
If you have additional questions, need further information, or would like to comment on our products or services, please write or phone:
1. Your local Honeywell Home and Building Control sales office (check white pages of phone directory).
2. Home and Building Control Customer Logistics
Honeywell Inc., 1985 Douglas Drive North
Minneapolis, Minnesota 55422-4386 (612) 951-1000
In Canada—Honeywell Limited/Honeywell Limitée, 740 Ellesmere Road, Scarborough, Ontario M1P 2V9. International sales and service
offices in all principal cities of the world. Manufacturing in Australia, Canada, Finland, France, Germany, Japan, Mexico, Netherlands, Spain,
Taiwan, United Kingdom, U.S.A.
Terminal Electrical Load 120 Vac 240 Vac
3
Burner
Full Load 5.2A 2.6A
Motor
Locked
Rotor
(inrush)
31.2A 15.6A
Ignition
a,b
3.0A 1.5A
Pilot Fuel Valve 25 VA 25 VA
4 Ignition
a
3.0A 1.5A
5 Gas Valve
b
125 VA 125 VA
