31 65-0086—2
RM7895A,B,C,D
TROUBLESHOOTING
TABLE 6—SEQUENCE AND STATUS HOLD MESSAGES (Continued)
Sequence Status
RUN The LEDs indicate the burner status, POWER, FLAME and
MAIN, which is the period of time after the Ignition Trials and
before the operating controller set point is reached. During this
time, the burner is firing under the control of the operating control-
ler (RM7895C,D).
RESET/ALARM TEST The LED indicates the burner status, POWER and ALARM. This
condition indicates the reset push button is pressed. If it is held for
more than four seconds, the alarm output is energized. The alarm
output will be de-energized after the reset pushbutton is released.
