RP2/RP4 User Guide 13
Media Types and Settings
5. After updating the New Value column, ensure that the Include column
checkbox is selected for the value, and click the Send button to send this
change to the printer.
6. Allow 30 seconds for the printer to reset.
If you have issues with media registration after sending these settings to the
printer, refer to Calibrate the Media on page 29.
Media Type
Gap Label Notch Edge Notch Center
Reflective
(Black Mark)
Continuous
Sensor Type
Gap Not Supported Gap
Black Mark (Top
or Bottom)
Continuous
Label Length
(set value)
Setting Description
Continuous Label Length
(1/100 inch)
Distance the printer will advance after pressing the Media Feed
button. Distance is measured in 1/100 inch, so 1000 = 10 inches.
Label Width (1/100 inch)
200 = 2 inch media
300 = 3 inch media
400 = 4 inch media
Maximum Label Length
(1/100 inch)
Distance must be greater than the length of your media. Distance
is measured in 1/100 inch, so 1000 = 10 inches.
Sensor Type
Gap = labels with gap
Continuous = media with no gap
Reflective = labels with Q-mark or black mark

Honeywell RP4 Specifications

General

Print Method	Direct Thermal
Resolution	203 dpi (8 dots/mm)
Print Width	4.1 inches (104 mm)
Max Print Speed	5 ips (127 mm/s)
Connectivity	USB, Bluetooth, Wi-Fi
Battery	Rechargeable, 7.4V, 2500 mAh
Durability	IP54
Drop Specification	1.8 m (6 ft) to concrete
Media Type	Labels, Receipts, Tags
Operating Temperature	14°F to 122°F (-10°C to 50°C)
Memory	128 MB RAM, 256 MB Flash
Weight	1.5 lbs (0.68 kg) with battery
