Fig. 5
Fig. 4
Mounting
Bracket
Screws
Mounting
Bracket
Canopy
Washer
4. Loosen all four mounting bracket screws. Remove
the two mounting bracket screws and washers from
the round holes of canopy. Set aside for later use.
Detach mounting bracket from canopy (Fig. 4).
5. Secure the mounting bracket to the outlet box using
screws washers provided with the outlet box (not
included) (Fig. 5).
Note: It is very important that you use proper hardware
when installing the mounting bracket as it supports
the fan.
Important: If using the angle mount, ensure that the
open end of the mounting bracket is installed facing
the peak of the ceiling.
6
MOUNTING BRACKET INSTALLATION
Mounting Bracket
Screw
Washer
To Next Page
