8 Write down the color of the wires
Check mark the wires that are connected to terminals. Next to the check mark,
write down the color of the wire. Do not include jumpers as a part of your count.
Check all that apply (Not all will apply):
Terminal Wire Color
Y
Y2
G
C
7 Record if you have wires in the
following terminals
Do not include jumpers as a part
of your count. The thermostat does
not need jumpers.
Terminal Wire Color
A or L/A
O/B
W2 or AUX
E
W
K
Terminal Wire Color
R
Rh
Rc
S and U terminals are not supported with this thermostat.
If there are wires in terminals that are not listed, you will need additional wir-
ing support. Visit resideo.com to find out if the thermostat will work for you.
Required (see step 9)
