T775L SERIES 2000 ELECTRONIC STAND-ALONE STAGING CONTROLLER
27 62-0257—11
Fig. 63. Program - Sensor A Max. Setpoint.
3.3.1. SP MAX A1 or BOILER MAX
(Setpoint maximum for Sensor A)
1. From the menu, use the  and  buttons to high-
light SP MAX A1.
2. Press the  button to display the maximum setpoint
value.
3. Use the  and  buttons to increase/decrease the
desired maximum setpoint temperature.
Default: 180°F (82°C)
Range: -40°F to 248°F (-40°C to 120°C)
4. Press the  button to accept the setpoint tempera-
ture and display the next option.
Fig. 64. Program - Sensor B Max. Setpoint.
3.3.2. RESET B1 or OUTSD MIN (Sensor B
value when at SP MAX A1 Setpoint)
1. From the menu, use the  and  buttons to high-
light RESET B1 or OUTSD MIN.
2. Press the  button to display the setpoint value.
3. Use the  and  buttons to increase/decrease the
desired setpoint temperature.
Default: 10°F (-12°C)
Range: -40°F to 248°F (-40°C to 120°C)
4. Press the  button to accept the value and display
the next option.
Fig. 65. Program - Sensor A Min. Setpoint.
3.3.3. SP MIN A2 or BOILER MIN (Setpoint
minimum for Sensor A)
1. From the menu, use the  and  buttons to high-
light SP MIN A2.
2. Press the  button to display the setpoint value.
3. Use the  and  buttons to increase/decrease the
desired minimum setpoint temperature.
Default: 140°F (60°C)
Range: -40°F to 248°F (-40°C to 120°C)
4. Press the  button to accept the setpoint tempera-
ture and display the next option.
Fig. 66. Program - Sensor B Min. Setpoint.
3.3.4. RESET B2 or OUTSD MAX (Sensor B
value when at MIN A2 Setpoint)
1. From the menu, use the  and  buttons to high-
light RESET B2.
2. Press the  button to display the setpoint value.
3. Use the  and  buttons to increase/decrease the
desired setpoint temperature.
Default: 60°F (16°C)
Range: -40°F to 248°F (-40°C to 120°C)
4. Press the  button to accept the value and display
the next option.
ENTER
MAXIMUM
SETPOINT FOR
SENSOR A
M24406
PROGRAM
LOOP 1
SP MAX A1
MENU
PROGRAM
LOOP 1
SP MAX A1
180
F
o
ENTER
SENSOR B
VALUE FOR
MAXIMUM
SETPOINT
PROGRAM
LOOP 1
RESET B1
MENU
PROGRAM
LOOP 1
RESET B1
10
F
o
M24407
ENTER
MINIMUM
SETPOINT
FOR
SENSOR A
PROGRAM
LOOP 1
SP MIN A2
MENU
PROGRAM
LOOP 1
SP MIN A2
140
F
o
M24408
PROGRAM
LOOP 1
RESET B2
MENU
PROGRAM
LOOP 1
RESET B2
60
F
o
ENTER
SENSOR B
VALUE FOR
MINIMUM
SETPOINT
M24409
