1. SETUP T775U SERIES 2000 CONTROLLER
23 62-0255–05
Fig. 50. Setup - Outputs - Options - Show Runtime.
1.3.3.4. SHOW RT (show run time hours)
1. Press the X button to display the Show RT values.
2. Use the S and T buttons to select YES or NO.
Default: YES
3. Press the X button to accept the value and return to
the Options menu.
Selecting YES shows the RT (run time) hours for each
relay on the home screen displays.
NOTE: Run times can be reset to zero for each individ-
ual relay. You must do this for each relay that
you want to reset to zero. See “1.3.4.3. RESET
RT (run time)” on page 24.
Fig. 51. Setup - Outputs - Options - Exit.
1.3.3.5. Exit Options Setup
Press the W button to exit the Options set up and return to
the Outputs menu.
or
Use the S and T buttons to highlight EXIT and press the
X button.
Continue with “1.3.4. Setting up the Relays”.
Fig. 52. Setup - Outputs - Relay Menu.
1.3.4. Setting up the Relays
1. From the Outputs menu, use the S and T buttons
to highlight the desired relay (1 or 2).
2. Press the X button to display the selected Relay
menu.
Continue with the remainder of this section to setup the
relay outputs.
Fig. 53. Setup - Outputs - Relay - Schedule.
1.3.4.1. SCHEDULE
This selection displays only if “Use Sched = YES” is
selected during the Output Options setup (see page 21).
When selected, individual outputs default to follow the
schedule.
1. Press the X button to display the Schedule values.
2. Use the S and T buttons to select YES or NO.
Default: YES
3. Press the X button to accept the value and return to
the Relay menu.
An individual output can be selected to be controlled or
not controlled by the schedule.
If NO is selected, the Setback selection does not appear
in the Program menu for this output.
