Honeywell V5055 User Manual

3 60-2102—7
V51E
SPECIFICATIONS
Fig. 2—V51E Assembly dimensions in in. [mm].
VALVE
SIZE (in.)
1 1/2
2
2 1/2
3
4
2 21/32
3 5/32
3 27/32
4 1/32
5 21/64
67.5
80.2
97.6
102.4
135.3
A
A
1
in. mm
1 9/16
1 13/16
2 5/16
2 25/64
3 5/32
39.7
46.0
58.7
60.7
80.2
B
B
in. mm
4 1/4
4 1/4
4 13/16
5
5 3/8
108.0
108.0
122.2
127.0
136.5
C
C
in. mm
3 1/32
3 17/32
4 23/32
4 23/32
5 17/64
77.0
89.7
119.9
119.9
133.8
D
D
in. mm
M9532
1 2 1
1 MAXIMUM DIMENSIONS.
NOMINAL DIMENSIONS.
2
V51E DIMENSIONS
