Honeywell V5055 User Manual

60-2307—10 4
V5055A-E
SPECIFICATIONS
REPLACEMENT PARTS:
Replacement Seal Assembly: Includes valve seal, bonnet
seal, and tube of lubricant.
133393A: for 3/4, 1, 1-1/4, and 1-1/2 in. valves
133392A: for 2, 2-1/2, and 3 in. valves.
137253A: for 4 in. valves.
Replacement Bonnet Assembly: Includes complete bon-
net assembly, plus the required replacement seal assem-
bly.
APPROVALS: The following combinations of V5055 Valves
(3/4 through 4 in.) and V4055, V4062 and V9055 Fluid
Power Actuators are approved by these agencies:
Underwriters Laboratories Inc. Listed: (File No. MH1639,
Guide No. YIOZ):
V4055A,B,D,E/V5055A,B,C,D,E
V4062/V5055A,B,C,E
V9055/V5055A,B,C,E
Valve
Model
Valve
Size (in.)
Replacement
Bonnet
Assembly
V5055A (On-Off) 3/4, 1, 1-1/4,
1-1/2
133398AA
2, 2-1/2, 3 133417AA
4 136911AA
V5055B
(Characterized guide)
3/4, 1, 1-1/4,
1-1/2
133398BA
2, 2-1/2, 3 133417BA
4 136911BA
V5055C (Valve-
closed indicator)
4 136911CA
V5055D (High
pressure On-Off)
3/4, 1, 1-1/4,
1-1/2
136308AA
2, 2-1/2, 3 136307AA
Fig. 2—Approximate dimensions of the 3/4 through 3 in. V5055 Valves with valve actuator in in. (mm).
B
E
F
C
D
A
1
1/4 INCH NPT
DOWNSTREAM 
TAP AND PLUG
1/4 INCH NPT UPSTREAM 
TAP AND PLUG
1
(32.5)
KNOCKOUT
FOR1/2 INCH
CONDUIT (4)
OCTAGON
1
9
32
27
32
(21.4)
3
23
32
5 (127)
(94.5)
6
3
4
(171.5)
ALLOW 2 IN. (51 mm) CLEARANCE FOR ACTUATOR REMOVAL.
M9585
3/4
1
1-1/4
1-1/2
2
2-1/2
3
VALVE 
SIZE
INCH
11-1/8
11-1/8
11-1/8
11-1/8
11-1/4
11-3/4
11-3/4
282.6
282.6
282.6
282.6
285.8
298.5
298.5
2-3/4
2-3/4
2-3/4
2-3/4
2-7/8
3-3/8
3-3/8
69.9
69.9
69.9
69.9
73.0
85.7
85.7
8-3/16
8-3/16
8-3/16
8-3/16
8-5/16
8-13/16
8-13/16
208.0
208.0
208.0
208.0
211.1
223.8
223.8
5-3/4
5-3/4
5-3/4
5-3/4
8-3/8
9-1/4
9-1/4
146.1
146.1
146.1
146.1
212.7
235.0
235.0
2-1/4
2-1/4
2-1/4
2-1/4
2-3/4
2-3/4
2-3/4
57.2
57.2
57.2
57.2
69.9
69.9
69.9
4-13/16
4-13/16
4-13/16
4-13/16
7-19/32
7-19/32
7-19/32
122.2
122.2
122.2
122.2
192.9
192.9
192.9
2-13/16
2-13/16
2-13/16
2-13/16
3-1/2
4-1/2
4-1/2
71.4
71.4
71.4
71.4
88.9
114.3
114.3
DIM A
IN. MM
DIM B
IN. MM
DIM C
IN. MM
DIM D
IN. MM
DIM E
IN. MM
DIM F
IN. MM
OCTAGON
IN. MM
