SOLDERING GUIDELINES
When hand soldering switch terminals, do not exceed five
seconds at 350 ºC [662 ºF] (exception for ZD Series switches:
Do not exceed five seconds at 300 °C [572 °F] or three seconds
at 350 °C [662 °F]). Contacting the switch housing with the
soldering device may damage the switch housing. Solder joints
must not be moved for at least one minute after soldering.
When wave soldering, do not exceed five seconds at 260 ºC
[500 ºF] or subject to aqueous wash. Use alcohol and swab to
clean terminals. Use of no-clean flux is recommended.
ENVIRONMENTAL OPERATING CHARACTERISTICS
Switch series Operating temperature range
ZX, ZD 40 °C to 85 °C [40 °F to 185 °F]
ZM, ZM1 0 °C to 120 °C [32 °F to 248 °F]
ZW
40 °C to 120 °C [40 °F to 248 °F]*
40 °C to 70 °C [40 °F to 158 °F]**
*Terminal types or pre-wired with high heat-resistant cables.
** Pre-wired with PVC cables.
