Attach hose holder
Position hose holder (B) onto handle by
matching tabs on rack with openings on
back of handle. Make sure bolts are
through holes.
4
The assembled cleaner will look like this
drawing. Model with powered hand tool
shown.
1-2
Attach upper handle
Remove clean solution tank (upper tank)
from carpet cleaner.
With cord hook (A) to back of carpet clean-
er, push upper handle down onto lower
handle. Push bolts into holes on front of
handle. If bolts will not go through hole
easily handle is not pushed completely
down.
1-3
1-6
1-9
1-4
1-5
1-7
1-8
When handle sections are completely
together, squeeze trigger (C) and
depress Clean Surge™ Button (D) on
upper handle.
You will hear a “snap” when the trig-
ger rod is in place.
A
C
D
B
Replace clean solution tank (upper
tank) by positioning bottom first. Press
on tank handle to snap top of tank into
place.
Place nuts in recessed areas on back
of hose holder. Hold each nut in place
while tightening each bolt securely
(from the front of the handle) with a
Phillips screwdriver.
Only two nuts are needed on this
model. The extra nut is not required but
has been provided for your conve-
nience.
Attach tool holder
Remove tool and taped screw from
holder. Insert projections on holder into
slots on back of cleaner.
Slide holder down into place. Insert
screw at (E) and tighten with a Phillips
screwdriver.
E
