FEATURES
1. D-Shaped Handle
2. Clean Boost™ Trigger
3. Solution Trigger
4. Mode Selection (wash/dry)
5. ON/OFF Switch
6. Carry Handle
7. Clean Water/Solution Tank
Release Button
8. Clean Water/Solution Tank
FEATURES
2
3
7
5
8
4
9
1
FRONT
BACK
10
12
13
14
11
6
9. Nozzle Release
10. Nozzle
11. Cord Clip
12. Cord Storage Hook (rotates)
13. Dirty Water Tank Release Button
14. Dirty Water Tank
15. Cord Storage Hook
16. Handle Release Pedal
