Hoover HDB 854 D User Manual

SETTING UP + INSTALLATION
Remove the polystyrene base and place the machine near
its permanent position (diagram 1).
Carefully cut through the hose retaining clip at the rear of
the appliance (diagram 2).
Remove the 3 fixing screws marked (A) and remove the 3
spacers marked (B) (diagram 3).
Remove the screw (C).
A spacer will fall inside the machine.
By tilting the machine, remove the above mentioned spacer.
Cover the 4 holes using the caps provided in the instruction
booklet pack (diagram 4).
WARNING:
DO NOT LEAVE THE PACKAGING WITHIN REACH OF CHILDREN AS IT IS A POTENTIAL
SOURCE OF DANGER.
Apply the insulation sheet of corrugated material to the base
as shown.
Use the 4 feet to level the machine with the floor:
a) Turn the nut clockwise to release the screw adjuster on the foot.
b) Rotate the foot to raise or lower it until it stands firmly on the
ground.
c) Lock the foot in position by turning the nut
anti-clockwise until it comes up against the bottom of the machine.
A
B
C
1
2
34
33
Appliance complies with European Directives 73/23/EEC and 89/336/EEC, replaced by
2006/95/EC and 2004/108/EC, and subsequent amendments.
Technical data
■ Max. load of dry laundry
■ Max. load of dry laundry for drying
■ Water pressure
Measurements
■ Width
■ Depth
■ Height
NB: For specifications regarding electrical data, see the data panel on the
front of the washing machine (porthole area) - as shown in diagram above.
Fig. 2
32
8 kg
5 kg
0,05 ÷ 0,8 MPa
60 cm
54 cm
82 cm

Hoover HDB 854 D Specifications

General

Door hinge	Left
Water fill	Cold
Drum volume	56 L
Control type	Buttons, Rotary
Loading type	Front-load
Drum material	Stainless steel
Product color	White
Viewing window	Yes
Custom panel-ready	No
Appliance placement	Freestanding
Drying capacity	5 kg
Washing capacity	8 kg
Delay start (max)	23 h
Residual moisture	44 %
Maximum spin speed	1400 RPM
Noise level (spin)	75 dB
Noise level (wash)	55 dB
Noise level (drying)	68 dB
Number of washing programs	15
Cycle time washing & drying	59 min
Current	10 A
Connected load	2150 W
AC input voltage	220-240 V
Water consumption washing per cycle	60 L
Energy consumption washing per cycle	1.36 kWh
Water consumption washing & drying per cycle	115 L
Energy consumption washing & drying per cycle	5.44 kWh
Cord length	1.8 m
Inlet hose length	1 m
Door opening angle	160 °

Weight and Dimensions

Depth	541 mm
Width	596 mm
Height	820 mm
Weight	68000 g
Package depth	600 mm
Package width	650 mm
Package height	890 mm
Package weight	70000 g
Door opening diameter	350 mm
Installation compartment depth	570 mm
Installation compartment height	825 mm
