Hoover HDB 854 D User Manual

Note: it is advisable to turn off the tap after each wash
to isolate the washing machine from the water supply.
For the washing machine to function properly the terminal end of the discharge hose (mouth)
must be at a minimum of 50 cm and a maximum of 85 cm from the ground.
ELECTRICAL CONNECTIONS
After installation, the appliance must be positioned so that the plug is accessible.
If the plug we supply does not fit
CUT IT OFF AND DESTROY IT!
You can’t use it on other appliances, and the exposed wires could be dangerous if plugged in.
To fit a replacement plug, proceed as follows:
Connect to the terminal in the plug
green and yellow wire marked with the letter E,
OR marked
with the symbol,
OR coloured green,
OR coloured green and yellow.
blue wire marked N
OR coloured black.
brown wire marked L
OR coloured red.
WARNING
This appliance must be earthed
Fuses and plugs
This appliance should be used only on a socket with a minimum rating of 13 Amp.
Our ready-fitted plug is already equipped with a 13 amp fuse which is BS 1362 ASTA
approved. Any replacement should be exactly the same.
If the fuse cover is lost, do not use the plug until it is replaced. A correct replacement fuse
cover (obtainable from your local retailer) must be the same colour as shown or named on
the insert on the base of the plug.
35
Note: we recommend you keep the screws to
immobilise the machine for future transit.
The Manufacturers will not be responsible for any
possible damage to the machine caused by not
following the rules relating to releasing the mechanism.
The user is responsible for all costs of installation.
Water connection
The appliance must be connected to the water mains using new
hose-sets.
The old hose-sets should not be re-used.
The machine has an inlet hose with 3/4" B.S.P threaded end
connection to attach between the threaded connector on the
appliance and the cold water supply.
This machine only uses cold water, therefore
only one hose is needed to connect to the cold
water supply. Do not connect to the hot supply.
Cold fill is an energy efficient system. Only the
water required for the washing is heated.There
is no loss of heat in the pipeline from a hot
water tank or boiler to the machine.
34
min 50 cm
max 85 cm
+2,6 mt max
max 100 cm
min 4 cm

Hoover HDB 854 D Specifications

General

Door hinge	Left
Water fill	Cold
Drum volume	56 L
Control type	Buttons, Rotary
Loading type	Front-load
Drum material	Stainless steel
Product color	White
Viewing window	Yes
Custom panel-ready	No
Appliance placement	Freestanding
Drying capacity	5 kg
Washing capacity	8 kg
Delay start (max)	23 h
Residual moisture	44 %
Maximum spin speed	1400 RPM
Noise level (spin)	75 dB
Noise level (wash)	55 dB
Noise level (drying)	68 dB
Number of washing programs	15
Cycle time washing & drying	59 min
Current	10 A
Connected load	2150 W
AC input voltage	220-240 V
Water consumption washing per cycle	60 L
Energy consumption washing per cycle	1.36 kWh
Water consumption washing & drying per cycle	115 L
Energy consumption washing & drying per cycle	5.44 kWh
Cord length	1.8 m
Inlet hose length	1 m
Door opening angle	160 °

Weight and Dimensions

Depth	541 mm
Width	596 mm
Height	820 mm
Weight	68000 g
Package depth	600 mm
Package width	650 mm
Package height	890 mm
Package weight	70000 g
Door opening diameter	350 mm
Installation compartment depth	570 mm
Installation compartment height	825 mm
