4
Make sure that the switch is in the
OFF position.
Slide handle section onto back of
handle.
Push screws into holes on back of
handle.
Tighten screws securely with a
Phillips screwdriver.
Remove powered hand tool (some
models) from plastic bag and return
it to the tool storage area.
Remove switch lock (C) above ON/
OFF switch (D) by pulling it straight
out. Dispose of switch lock.
If switch lock has come off during
assembly, make sure switch is in
OFF position (down) before plug-
ging into electrical outlet.
1-3
1-41-2
1-5
B
1-6
Open tool cover on cleaner body
(B).
Remove powered hand tool (some
models).
C
A
D
Remove cardboard (A) and screws
from handle section. Discard card-
board.
ST E P 1 Attach handle
