13.
WARNING! To reduce the risk of personal injury, remove the powerhead from the rod before cleaning
and servicing the roller brush.
Maintenance
Cleaning the Roller Brush
Cleaning or Replacing the Exhaust Filter
1. Using a flat-head screwdriver or coin, turn the locking tab to the
unlock position. The locking tab can now be removed to access the
roller brush.
2. Gently remove the roller brush as shown, and clean as required.
1. To remove the exhaust filter, press the Exhaust Filter Release
Buttons and remove from the cleaner.
NOTE: It is recommenced to replace the exhaust filter every 6 months.
1. Press the Dust Bin Lid Release Button to access the cyclone separator.
2. Turn the cyclone separator to unlock and remove it from the dust bin, as shown.
NOTE: The cyclone separator can be washed using lukewarm water. The cyclone separator need to air
dry for 24 hours before reinstalling.
Cleaning the Cyclone Separator
To Next Page
