HORI Split Pad Compact - Assign Mode; How to Set Up Assign Mode; How to Unassign Functions

Assign mode allows you to assign button functions to the FL
and FR buttons.
*Cannot be assigned to multiple buttons at the same time
FL Button
Assignable buttons
L Button / ZL Button / L Stick Button
/ D-pad (UP, DOWN, LEFT or RIGHT)
/ - Button
R Button / ZR Button / R Stick Button
/ A Button / B Button / X Button
/ Y Button /
＋
Button
FR Button
Assignable buttons
* Please use the ASSIGN Button (L) when setting button functions to FL Button.
Please use the ASSIGN Button (R) when setting button function to FR Button.
How to set up
Press the button
you want to
assign a function
to FL/FR
While pressing
ASSIGN Button
(L/R)
＋
A
ASSIGN LED
turns Red
LED
On
FR
A
ASSIGN LED
LED
Off
FR
A
Unassign
Press
FL/FR button
While pressing
ASSIGN Button
(L/R)
＋
FR
Assign Mode
