310.2007 TR10A036-C RE
TABLE OF CONTENTS PAGE
A Supplied Items 2
B Required Tools for Installation 2
1 IMPORTANT NOTES 4
1.1 Important safety instructions 4
1.1.1 Warranty 4
1.1.2 Checking the door / door system 4
1.2 Important instructions for safe installation 4
1.2.1 Before installing the garage door operator 4
1.3 Warnings 5
1.4 Maintenance advice 5
1.5 Information on the illustrated section 5
Illustrated Section 18-32
2 DEFINITIONS 33
3 PREPARING FOR INSTALLATION 33
3.1 Required clearance for installing the operator 33
3.1.1 Before installing the boom 33
3.1.2 Boom operating modes 33
3.1.3 Manual operation 33
3.1.4 Automatic operation 34
3.2 Installing the garage door operator 34
3.2.1 Centrally positioned lock on a sectional door 34
3.2.2 Off-centred reinforcement profile on a sectional door 34
3.2.3 Tensioning the toothed belt 34
3.2.4 Establishing the door's end-of-travel positions
by installing the limit stops 34
3.3 Electrical connection 34
3.3.1 Connecting additional components 35
3.3.2 Connecting external IMPULSE buttons
to start or stop travel cycles 35
3.3.3 Connecting an additional external radio receiver 35
3.3.4 Connecting a 2-wire photocell 35
3.3.5 Connecting a wicket door contact 35
3.3.6 Connecting the options relay PR 1 35
3.3.7 Emergency accumulator 35
4 PUTTING THE OPERATOR INTO SERVICE 35
4.1 Preparation 35
4.2 Deleting the door data 35
4.3 Learning cycles 35
4.4 Setting the forces 36
4.5 Radio receiver 36
4.5.1 Integral radio module 36
4.5.2 Connecting an external radio receiver 36
4.5.3 Deleting the data of the internal radio module 36
4.6 Setting the DIL-switches 36
4.6.1 Automatic timer 36
4.6.2 CLOSE end-of-travel signalling
DIL-switch A
➜ OFF / DIL-switch B ➜ ON 37
4.6.3 Advance warning phase
DIL-switch A
➜ ON / DIL-switch B ➜ OFF 37
4.6.4 External lighting
DIL-switch A
➜ OFF / DIL-switch B ➜ OFF 37
4.6.5 Door type
DIL-switch C 37
4.6.6 Photocell
DIL-switch D 37
4.6.7 Stop / static current circuit with self-monitoring
DIL-switch E 37
4.6.8 Door maintenance indication
DIL-switch F 37
5 USING THE GARAGE DOOR OPERATOR 37
5.1 Normal operation 37
5.2 Power failure backup with the emergency
accumulator 38
5.3 Operation after actuating the mechanical release 38
6 HAND TRANSMITTER 38
6.1 Important notes on using the hand transmitter 38
6.2 Restoring the factory code 38
7 CHANGING THE LIGHT BULB 38
8 SIGNALS FROM OPERATOR LIGHTING
WHEN MAINS POWER ON 38
9 ERROR MESSAGES 39
10 DISMANTLING 39
11 OPTIONAL ACCESSORIES
(NOT INCLUDED IN THE SCOPE OF SUPPLY) 39
12 TERMS AND CONDITIONS OF THE WARRANTY 39
13 TECHNICAL DATA 40
ENGLISH
