70 04.2007 TR10A041-C RE
Universal fitting: For up-and-over and sectional
doors
Door speed: Depending on the door type,
door size, door action and
weight
- closing: approx. 14 cm/s
- opening: approx. 22 cm/s
Air-borne noise
of garage door
operator: ≤ 70 dB (A)
Boom: Extremely flat (30 mm) with
integrated door security kit
and maintenance-free toothed
belt.
Application: Exclusively for garages in the
domestic sector. Not suitable
for industrial / commercial use.
11.1 Spare lamp
To insert / replace bulb for operator lighting
– see fig. 33
To adjust operator lighting
– see section 6.2 (menu 2)
Type: only cold-light reflector lamp
with protective glass and UV
protection
Base: GU 5.3
Wattage: 20 W
Voltage: 12 V
Lighting angle: 36°-60°
Diameter: 51 mm
Lamp colour: clear
Note
When replacing the cold-light reflector lamp, make sure that
the operator has been switched off first.
ENGLISH
