5
Turn over the machine and place your cutter onto the comb.
The sharpened sides of both the comb and cutter should face
each other. Locate the cutter onto the conical pins on the
forks.
Secure the cutter by turning
the tension knob clockwise.
Apply enough tension to
secure the cutter.
Setting the Lead
Adjust the comb so that as the cutter travels over the comb’s
central tooth, at least 1.5 mm of the comb tooth’s at ground
surface is clear of the cutter’s tip.
Finally, rmly tighten the comb screws.
1.5mm
Central tooth
1.5mm
COMB AND CUTTER SET UP
