8
2. Ice Making Assembly
Seal Bolt
Gear Motor
Spline Coupling
Housing and
Lower Bearing
O-Ring
Mechanical Seal
Cylinder
Auger
Extruding Head
and Upper
Bearing
Cutter (motionless)
Insulation
Socket Head
Cap Screw
with Washer
Hex Head
Bolt with
Washer
Evaporator Flange
