9
3. Water/Refrigeration Circuit Diagram
Drier
Condenser
Fan Motor
Condenser
Compressor
Float Switch
Water Reservoir
Water Level
Gear
Motor
Evaporator
Assembly
Water Inlet
Evaporator Water
Supply Hose
Capillary Tube
Overow Hose
Suction
Discharge
Inlet Water Valve
Drain Valve Drain Hose
Evaporator Condensate
Drain Pan (Drip Pan) Hose
Evaporator Condensate
Drain Pan (Drip Pan)
Gear Motor
Drain Pan
Bin Drain Hose
To Bin
Gear Motor Drain Pan Hose
To Drain
Drain Valve
