HOTA F6+ - Page 20

Regenerative Discharge
16
Regenerative Discharge
LiPo-6S(3.60V) 56% 00:00:06
CH1
-3 mAh
23.46V
-3.1A -71W
3.898V
3.897V
1
4
3.900V
3.905V
2
5
3.903V
3.893V
3
6
00:00:00
CH2
Standby
F6+ 4-Channel DC Smart Charger
Operation and Setup
Working parameters Display
Regenerative Discharge status : Simple Operation
1. Connect the battery ,which is going to receive power ,to the input ends of the charger
and wait for the system to complete the self-checking . Connect the discharge battery
to the output ends of the charger in the standby interface ;
2. In the standby state , short press the OK key to pop up the “Task Settings"
menu, set the task to “Regenerative Discharge" ; adjust the task parameters, short
press the speed shuttle key to start the task ;
Press △ key or ▽ key during operation can switch the display information in the lower half of the screen，
which are cell voltage and run data，the cell voltage and internal resistance can only be displayed in the
mode of balance charging.
3. When the task of Regenerative Discharge is executing, short press the OK key
can pop up the "Adjust Task” menu to adjust the Regenerative Discharge current ;
long press the CH key can stop the current task ;
4. Enjoy.
Operation
Time
Capacity
charged
Task Status
Output
Current
Total Battery
Voltage
Output
Power
Operation
Time
Cell Voltage
Current
channel
Current
channel
Battery parameters and
Percentage of completion
