07
F6+ 4-Channel DC Smart Charger
How to conform the charging current
Operative Skills
It is important to know the maximum charging current of the battery before charging as
excessive current could influence the life span of battery ,even cause damages. In addi-
tion, excessive current can cause heating even explosion of the battery during the
charging process.
The charging and discharge capacity of battery is usually marked with C value. Multiply-
ing the charging C value and battery capacity equals to the maximum charging current
supported by the battery. For example, for a 1000 mAh battery with a charging capacity
of 5C, its maximum charging current would be l000 * 5 = 5000mA; that is , the maximum
charging current is 5A.
For a lithium battery, if it is impossible to confirm the supported charging C value, please
set the charging current below 1C for the sake of its (lithium battery) safety.
The reference relation between C value and charging time: charging time >= 60
minutes/ charging C value (it therefore needs around 60~70 minutes to complete
charging with 1C). Due to the differences in battery power conversion efficiency, this
period of time to complete the charging may be extended.
1. Connect power supply to the charger's AC or
DC port, wait for the system to complete the
self-checking. Connect the battery to the charger
under standby interface, and short press the CH
key to select the switching channel freely，after
select the corresponding channel，short press
the OK key to make the “Task Setting” menu to
pop up.
2.When the task is being executed, you can short
press the OK key to pop up the “ Adjust Task”
menu to adjust the task's current or stop the
task.
3.Long press CH key to quick stop current opera-
tion or to enter the “Task Settings” menu for
corresponding channel.
Operation and Setup
通道键 确认键
向上键
向下键
