Hotblast 1357M - Parts List

19
1
25541G
Cabinet Side (Left & Right)
1357M
2
25467G
1557M
2 88032 Flue Collar Gasket 2
3 40246 Flue Collar 1
N/S 83227 Bolt, 1/4-20 x 1" 6
N/S 83250 Kep Nut, 1/4-20 6
4
25540G
Cabinet Back
1357M
1
23459G
1557M
5
25561G
Cabinet Top
1357M
1
25466G
1557M
N/S 891214 8" Collar 2
6 68217 Feed Door Assy. (Includes Gasket - 88057) 1
7 22662 Bracket, Feed Door 1
8 24232 Spacer, Hinge 1
9 891097 Locking Mechanism, Feed Door 1
10 68218 Ash Door Assy. (Includes Gasket - 88066) 1
11 86626 Latch, Door 1
12 83461 Washer (1" OD, 7/16" ID) 1
13 83274 Lock Nut, 3/8-16 1
14 891098 Handle Assy. w/Handle Bushing 1
15 23859B Draft Cap, Painted 1
16 89574 Handle, Spring 2
17 23800 Smoke Curtain 1
18 23787 Clip, Smoke Curtain 2
19 83445 1/4-20 x 1-1/4 Carriage Bolt 2
20 83250 Kep Nut, 1/4-20 2
21
68238
Ash Pan
1357M
1
68228
1557M
22
23397
Bafe, Flue
1357M
1
23398
1557M
2
23 22761B Flue Collar Ring 1
24 22762B Forced Draft Ring 1
25 86402 1-1/2" Pipe Plug 1
26 80230 Blower
1357M
1
1557M
2
27 89319 Gasket, Blower
1357M
1
1557M
2
28 83340 1/4-20 Clipnut
1357M
4
1557M
8
N/S 83339 Bolt (1/4-20 x 3/4")
1357M
4
1557M
8
29 22140 Relay Box Bracket 1
30 80131 Junction Box (4 x 4) 1
31 80231 Junction Box Cover 1
32 80314 Thermodisc (60T12) 1
33 68234 Blower Thermostat Bracket 1
34 89066 Firebrick (4.5 x 9 x 1.25)
1357M
10
1557M
12
35 40264 Liner, Front/Rear
1357M
2
36 40256 Grate Frame, Shaker
1357M
1
1557M
2
37 40257 Grate, Shaker
1357M
1
1557M
2
38 40260 Handle, Shaker 1
39 40258 Liner - Rear
1557M
1
40 40269 Liner - Front
1557M
1
41 69396 Control Plate Assembly 1
42 25200 Slide Damper 1
43 89041 Spring 1
44 83278 #10 Flat Washer 3
45 83244 10-24 Kep Nut 3
46 89943 Knob, Slide Damper 1
47 25197G Control Box Cover 1
48 25199G Pull Handle 1
49 83895 10-24 x 1-3/4 CS Machine Screw 1
N/S = Not Shown Color Code: G = Green
Key Part No. Description Model Qty.
Parts List
Key Part No. Description Model Qty.
IN ORDER TO MAINTAIN WARRANTY, COMPONENTS MUST BE REPLACED USING ORIGINAL
MANUFACTURERS PARTS PURCHASED THROUGH YOUR DEALER OR DIRECTLY FROM THE
APPLIANCE MANUFACTURER.
USE OF THIRD PARTY COMPONENTS WILL VOID THE WARRANTY.
