The appliance shall be installed on a floor with adequate load-bearing capacity. If the existing construction
does not meet this requirement, suitable measures (e.g. load distributing plate) should be provided to achieve
it.
Commissioning and Handover
Upon completion of the installation, allow a suitable period of time for any fire cement and mortar to dry
out. A small fire may then be lit and checked to ensure the smoke and fumes are taken from the stove up the
chimney and emitted safely to atmosphere.
Advise the customer not to run the stove at full output for at 3 – 4 days. Explain that the stoves can provide
much more or less than their rated heat outputs depending upon how they are burnt and fuels and fuel loads
used.
On completion of the installation and commissioning, ensure that the operating instructions and operating
tools (including glove) for the stove are left with the customer. You must be sure to advise the customer on
the correct use of the appliance with the fuels likely to be used on the stove and warn them to use only the
recommended fuels for the stove.
Advise the user on what to do should smoke or fumes be emitted into the room from the stove – see Safety
Notes section. The user should be warned that they MUST use a suitable fireguard in the presence of
children, aged and/or infirm persons.
5.0 Technical Data
Technical Specifications (Wood)
HH4SE
Nominal Heat Output kW 4.2 6.1 7.5
Efficiency % 76.6 81 72.1
CO Emission (@13% O2) % 0.84 0.18 0.17
Flue Gas Temp (avg. at nominal output) °C *247 *285 *350
Flue Gas Mass Flow g/s 3.5 4.4 7.3
Refuel Period hr 1.5 1 1
Flue Outlet Size Inch 5” 5” 6”
Product Weight (Packed) kg 85 118 143
Maximum Log Length mm 260 300 340
*Average reading at nominal output
6.0 Operating Instructions
This appliance is not designed for open operation and therefore should not be operated with the doors open,
this could cause excessive smoke and could also harm the appliance.
This stove is designed to burn cleanly with high efficiency. If used correctly this stove will burn with the
very useful feature of clean glass. However, for this product to work properly it must be used correctly.
It is essential that the stove has an adequate air supply for combustion and ventilation. The primary and
secondary air inlets must be kept clear from obstruction.
