HOTOWELL HTW-WF06 Series User Manual

Smart Wifi Thermostat
Reference No.:HTW-WF06 Series
- 4 - Version 2018-1.0
The installation personnel with non-professional training shall not perform this operation!
During thermostat power off, Press these 2 buttons M & simultaneously and hold for 5 seconds to enter
ISU process. Press to adjust the configurable parameter value, and press M to switch to next parameters.
The ISU process will automatically exit and be confirmed after 5 seconds with no operation.
Parameter
Function
Configurable Value Default
1 Temperature calibration
-7°C to +9°C (internal sensor) -1
2 Dead Zone
1°C to 5°C (Switching differential) 1
3 Keypad Lock type
00: = All buttons will lock except the Power button
01: = All buttons will lock
01
4 Sensor selection
In = Internal sensor(to control or limit the temperature)
OU= External sensor(to control or limit the temperature)
Al = internal sensor to control temperature, and external sensor
to limit the floor temperature.
Notes: Please make sure configure the right sensor. The thermostat
display Err. If wrongly configured.
In for model:
-3A
-NV
Al for model:
-16A
5 Min. set-point limit
5°C - 15°C 05
6 Max. set-point limit
15°C - 45°C 35
7 Temperature Display
00 ： display both set-point and room temp.
01 ： display set-point only
00
8
Low Temperature
Protection
0°C - 10°C 00
9
High Temperature
Protection
25°C - 70°C 45
A Economy Mode
0 ： Normal mode
1 ： Energy Saving mode
0
B Economy Temperature
0°C - 30°C 20
C Standby Brightness
3-99 04
 Products are warranted for 2 full year (checking and repairing
services) from the date of purchase which products are not
being damaged by any man-made factors.
 Service outwith the warranty period may incur an extra charge.
 More details please contact with Hotowell directly.
Installer Set-UP Process (ISU)
Warranty

HOTOWELL HTW-WF06 Series Specifications

General

Brand	HOTOWELL
Model	HTW-WF06 Series
Category	Thermostat
Language	English
