REHANG THE REFRIGERATOR
DOOR
Lower the refrigerator door onto the bottom
hinge pin.
Installation Instructions
TRANSFER FREEZER DOOR
HANDLE TO THE RIGHT
Remove the screws holding the handle to the top and
bottom of the door. Remove handle.
8
Move the plug button on the right side of the door to
the handle screw hole on the left side.
Reattach the handle on the opposite side using the
holes closest to the edge of the door.
9
Straighten the door and line it up with the center
hinge bracket.
Reinstall the center hinge pin with a 3/8″ socket.
Turn it until it extends through the hinge bracket
and into the door.
REVERSING THE DOOR SWING (CONT.)
Plastic
Washer
Plastic Washer
Refrigerator Door
Hinge Pin
Center Hinge
Bracket
22
REHANG THE FREEZER DOOR
Lower the freezer door onto the center hinge pin.
Be sure the washer is in place.
10
Lift the top hinge so the pin fits into the door socket.
Support the door on the handle side and make sure
the door is straight and the gap between the doors is
even across the front. While holding the door in
place, tighten the top hinge screws.
Center Hinge Pin
Plastic Washer
To Next Page
