Hotpoint BS41X - Grill Pan and Handle

The grill pan handle is detachable from the pan, to facilitate cleaning and storage.
The grill pan handle can be fixed as follows:
Step 1 Remove screw & washers from the grill pan bracket (a).
Step 2 Tilt the handle over the recess (b).
Step 3 Slide it towards the centre of the pan (c).
Step 4 Locate the handle over the bracket (d).
For a fixed handle, replace screw & washers and ensure they are fully
tightened up. If a detachable handle is required, do not replace screw &
washers.
GRILL PAN AND
FOOD GRID
DOOR POSITION FOR
GRILLING
GRILL PAN & HANDLE
14
Note: If a fixed handle is required, the grill pan is unable to be stored in the oven
with the door closed and cannot be used as a meat pan.
Note:Do not grill with the grill/oven door
closed.
Step 1 Step 2 Step 3 Step 4
GRILL PAN
FOOD GRID
(a)
(b)
(c)
(d)
