Hotspot Franklin T10 User Manual

4. Enter the related parameters as described in the following table.
5. Click Save Change to save your settings.
-
Firewall IPv6
From the Web UI, click Settings > Advanced Router > Firewall IPv6. You may set up
firewall rules to protect your network from virus and malicious activity on the Internet.
Parameters
Description
Name
Enter a name for the rule
WAN Port
Set the WAN port
LAN IP Address
Enter the LAN IP address
LAN Port
Set the LAN port
Protocol
Set which protocol will be used for filtering
Status
Set how to handle the packet if it matches with the rule
'36

Hotspot Franklin T10 Specifications

General

Model	Franklin T10
Category	Wireless Access Point
Network Compatibility	4G LTE
Wi-Fi Technology	802.11 b/g/n
Wi-Fi Frequency	2.4 GHz
Max Connected Devices	15
Battery Capacity	2000 mAh
4G LTE Bands	B2, B4, B5, B12, B66
Display	LCD
