HotSpring Pulse User Manual

x Page 9 x
BOLT
®
(Model BLT)
Dimensions
NOTE: All dimensions are approximate; measure your spa
before making critical design or pathway decisions.
NOTE: Watkins Manufacturing Corporation recommends that the Bolt be installed on a minimum 4” (10 cm) thick
reinforced concrete pad or structurally sound deck able to support the “dead weight” found in the spa specification
chart.
WARNING: The Bolt must not be shimmed in any manner.
Pre-Delivery Instructions Page 9
BOLT
80” (203.2 cm)
80"
(203.2 cm)
3.5" (8.9 cm)
29.5 " 74.9 cm)
33" (83.8 cm)
65 1/2" (166.4 cm)
18.5” (47 cm)
65” (165.1 cm)
34” (86.4 cm )
(Bottom view)
Door
Drain
Upside Down View
of Spa
Electrical Cutout 1.5" (4.4 cm)
DoorDoor
(Front view)
