Hotsy 1720 User Manual

35Hotsy 1700 Operator’s Manual 8.914-380.0 - W
VBR Unloader Valve Parts List
REF REF NO. PART NO. QTY DESCRIPTION NOTES
- 70-080307 8.932-687.0 1 SPACER, BLUE
9 70-120606 8.932-695.0 1 STEM KIT “D”
10 70-000901 8.717-078.0 2 O-RING, BACK UP KIT “C”
11 70-060121 8.932-682.0 1 O-RING, STEM KIT “C”
12 70-160117 9.802-925.0 2 PLUG, 3/8
13 70-060306 9.803-198.0 2 WASHER, 3/8
14 70-020413 8.717-146.0 1 BODY
15 70-060122 9.803-948.0 1 O-RING, SEAT KIT “B”
16 70-150306 8.932-703.0 1 SEAT KIT “B”
17 70-150400 8.730-888.0 1 BALL, 7/16 KIT “B”
18 70-090011 8.932-688.0 1 SPRING KIT “B”
19 70-060118 8.932-681.0 2 O-RING, CONNECTOR KIT “B”
20 70-140703 8.932-698.0 1 CONNECTOR, INLET
21 70-150505 8.932-705.0 1 PIN KIT “C”
22 70-000900 8.717-077.0 1 O-RING, BACKUP 106 KIT “C”
23 70-060120 - 1 O-RING, STEM KIT “C”
24 70-060308 9.803-950.0 1 WASHER, 1/4
25 70-160121 9.803-951.0 1 PLUG, 1/4
26 70-110211 8.717-284.0 1 POPPET
27 70-090004 8.933-017.0 1 SPRING KIT “A”
28 70-140704 9.802-891.0 1 CONNECTOR, OUTLET KIT “A”
