16 M9 Transfer Instructions For Use (M999-19, Version 10, 2021-12)
6.8 CASTORS WITH 5
TH
WHEEL (OPTION)
The 5
th
wheel is free to swivel in the neutral position and locks in line with intended direction of travel in the steer
position. This allows the stretcher to be easily steered by one person.
1. Brake position
• Push the red pedal down.
• All four castors are locked.
2. Neutral position
• Pedals are horizontal.
• All four castors and 5
th
wheel are free to swivel and roll.
3. Steer position
• Push the green pedal down.
• Push the stretcher in the intended direction of travel and the 5
th
wheel will lock into position for steering.
6. OPERATION
Figure 15. 5th wheel
5th wheel
