M9 Transfer Instructions For Use (M999-19, Version 10, 2021-12) 17
Figure 16. Push handle in raised position
6. OPERATION
Figure 17. Push handle in folded down position.
Figure 18. Bed end
6.9 BED ENDS
The stretcher is fitted with integrated fold down push handles at the head end. A bed end is an available option
for the foot end.
Push handles
To fold down:
1. Hold the handles and lift upwards.
2. Fold in and down into recess on the deck.
To raise:
1. Reverse the above actions.
Bed end (Option)
To install:
1. Hold the bed end with both hands.
2. Lower the legs into the sockets on the deck.
To remove:
1. Reverse the above actions.
Lift
Fold down
