Front-facing webcamera
NOTE: The front-facing webcamera and cable are included in the Webcamera Kit, spare part
number 739008-001.
Before removing the front-facing webcamera, follow these steps:
1. Turn off the tablet. If you are unsure whether the tablet is off or in Hibernation, turn the tablet on,
and then shut it down through the operating system.
2. Disconnect the power from the tablet by unplugging the power cord from the tablet.
3. Disconnect all external devices from the tablet.
4. Remove the back cover (see
Back cover on page 12).
5. Disconnect the battery cable from the system board (see
Battery on page 14).
Remove the front-facing webcamera:
1. Disconnect the front-facing webcamera cable (1) from the system board.
2. Release the front-facing webcamera (2) from the mold built into the display panel assembly.
3. Remove the front-facing webcamera and cable.
Reverse this procedure to install the front-facing webcamera.
Front-facing webcamera
23
