Speakers
Description Spare part number
Speaker Kit L23221-001
Before removing the speakers, follow these steps:
1. Shut down the computer.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by rst unplugging the power cord from the AC outlet and then
unplugging the AC adapter from the computer.
4. Remove the bottom cover (see Bottom cover on page 29).
5. Remove the battery (see Battery on page 31).
Remove the speakers:
1. Disconnect the speaker cable from the system board (1).
2. Lift the tape that secures the speaker cable to the system board (2), and then lift the speakers from the
computer (3).
Reverse this procedure to install the speakers.
40 Chapter 5 Removal and replacement procedures for Authorized Service Provider parts
