Item Component Spare part
number
(12) Heat sink assembly (includes replacement thermal materials)
For use in models with AMD Radeon graphics 926876-001
For use in models with Nvidia GeForce graphics 930615-001
(13) Fan 926875-001
(14) Hard drive, 2.5 inch (does not include bracket, connector board, or cable)
NOTE: The hard drive cable is available using spare part number 926874-001.
2-TB, 5400-rpm 912487-855
1-TB, 7200-rpm 766644-005
(15) Hard drive bracket 926877-001
(16) RTC battery not spared
(17) System board (includes replacement thermal materials)
All system boards use the following part numbers:
xxxxxx-001: Non-Windows operating systems
xxxxxx-601: Windows 10 operating system
For use in models with Nvidia GeForce discrete graphics memory:
●
Intel Core i7-7700HQ processor and 4 GB of discrete graphics memory 926305-xx1
●
Intel Core i7-7700HQ processor and 2 GB of discrete graphics memory 926304-xx1
●
Intel Core i5-7300HQ processor and 4 GB of discrete graphics memory 926307-xx1
●
Intel Core i5-7300HQ processor and 2 GB of discrete graphics memory 926306-xx1
For use in models with AMD Radeon discrete graphics memory:
●
Intel Core i7-7700HQ processor 926308-xx1
●
Intel Core i5-7300HQ processor 926309-xx1
(18) Speakers (includes left and right speakers and cable) 926892-001
(19) Battery (4 cell, 70 Wh, 4.55 Ah) 917724-855
(20) Rubber Kit
For use in black and green models 926889-001
For use in black and white models 926890-001
(21) Bottom cover
For use in black and green models 926864-001
For use in black and white models 926863-001
Computer major components 19
