System board
NOTE: The system board spare part kit includes replacement thermal materials.
Description Spare part number
System board (includes processor and replacement thermal materials):
All system boards use the following part numbers:
xxxxxx-001: Without the Windows operating system
xxxxxx-501: Windows 8.1 Standard
xxxxxx-601: Windows 8.1 Professional
Touch screen models:
●
Intel Celeron N2830 processor and UMA graphics 775396-xxx
●
Intel Pentium N3540 processor and UMA graphics 788288-xxx
●
Intel Core i3-4005U processor and UMA graphics 775395-xxx
●
Intel Core i3-4030U processor and UMA graphics 779470-xxx
●
Intel Core i3-4030U processor and 2 GB of discrete graphics 779471-xxx
●
Intel Core i3-5005U processor and UMA graphics 790675-xxx
●
Intel Core i3-5010U processor and UMA graphics 801860-xxx
●
Intel Core i5-5200U processor and UMA graphics 790673-xxx
Non-touch screen models:
●
Intel Celeron N2805 processor and UMA graphics 789106-xxx
●
Intel Celeron N2815 processor and UMA graphics 759879-xxx
●
Intel Celeron N2820 processor and UMA graphics 789107-xxx
●
Intel Celeron N2830 processor and UMA graphics 764104-xxx
●
Intel Celeron N2840 processor and UMA graphics 788289-xxx
●
Intel Celeron N2920 processor and UMA graphics 789108-xxx
●
Intel Pentium N3520 processor and UMA graphics 759878-xxx
●
Intel Pentium N3530 processor and UMA graphics 764103-xxx
●
Intel Pentium N3540 processor and UMA graphics 788287-xxx
●
Intel Pentium N3540 processor and 1 GB of discrete graphics 788290-xxx
●
Intel Core i3-3217U processor and 2 GB of discrete graphics 760969-xxx
●
Intel Core i3-3217U processor and 1 GB of discrete graphics 759874-xxx
●
Intel Core i3-3217U processor and UMA graphics 759873-xxx
●
Intel Core i3-4005U processor and UMA graphics 765444-xxx
●
Intel Core i3-4005U processor and 1 GB of discrete graphics 775393-xxx
●
Intel Core i3-4005U processor and 2 GB of discrete graphics 775394-xxx
●
Intel Core i3-4010U processor and UMA graphics 759875-xxx
66 Chapter 6 Removal and replacement procedures for Authorized Service Provider parts
