Table 3-1 Computer major components and their descriptions
Item Component Spare part
number
(1) Display
NOTE: Displays are not spared as whole units. Display subcomponent spare parts are available. For
spare part information, see Display assembly subcomponents on page 22.
Not spared
(2) Top cover/keyboard
NOTE: For a detailed list of country codes, see Top cover with keyboard on page 76.
Keyboard, no backlight, jet black L20387-xx1
Keyboard, no backlight, full-featured models, snow white L20388-xx1
Keyboard, no backlight, defeatured models, snow white L23066-xx1
Keyboard, no backlight, ash silver L20386-xx1
Keyboard, backlit, ash silver (available only with -001 United States, -002 India, and -DB1 Canadian
French keyboards)
L23074-xx1
Keyboard, no backlight, iridescent pale rose gold (available only with -001 United States keyboards) L28504-001
Keyboard, backlit, iridescent pale rose gold (available only with -001 United States keyboards) L28505-001
Keyboard, no backlight, iridescent ceramic white (available only with -001 United States keyboards) L28506-001
Keyboard, backlit, iridescent ceramic white (available only with -001 United States keyboards) L28507-001
Keyboard, no backlight, ocean teal (available only with -001 United States keyboards) L31735-001
Keyboard, no backlight, Real Tree (available only with -001 United States keyboards) L31736-001
Keyboard, no backlight, natural silver (available only with -002 India keyboards) L32368-002
Keyboard, backlit, ocean teal (available only with -001 United States keyboards) L32863-001
Keyboard, backlit, natural silver (available only with -002 India keyboards) L32864-002
(3) TouchPad module L20449-001
(4) TouchPad button board not spared
(5) Speakers (include cable) L20453-001
(6) Power connector cable (DC-in) L20475-001
(7) System board
NOTE: All system board spare part kits include replacement thermal material.
All system boards use the following part numbers:
xxxxxx-001: Non-Windows operating systems
xxxxxx-601: Windows operating system
For use in models with discrete graphics memory:
● AMD Athlon 300U processor and Radeon 530 graphics L53469-xx1
● AMD Ryzen 3-3200U processor and Radeon 530 graphics L46517-xx1
● AMD Ryzen 3-2200U processor and Radeon 530 graphics L20668-xx1
● AMD A9-9425 processor and Radeon 530 graphics L46513-xx1
Computer major components 17
