Power connector cable (DC-in)
Table 6-16 Power connector cable description and part number
Description Spare part number
Power connector cable L20475-001
Before removing the power connector cable, follow these steps:
1. Prepare the computer for disassembly (Preparation for disassembly on page 33).
2. Remove the optical drive (see Optical drive on page 34).
3. Remove the bottom cover (see Bottom cover on page 38).
4. Remove the battery (see Battery on page 41).
5. Remove the system board (see System board on page 71).
6. Remove the display (see Display assembly on page 61).
Remove the power connector cable:
1. Remove the cable from the clips built into the computer (1).
2. Remove the power connector cable from the computer (2).
Reverse this procedure to install the power connector cable.
Component replacement procedures 75

HP 15 Series Specifications

General

Processor	AMD Ryzen 7
Display	15.6-inch HD (1366 x 768) or FHD (1920 x 1080)
Storage	1TB SSD
Graphics	AMD Radeon Graphics
Operating System	Windows 11 Home/Pro
Battery	3-cell
Connectivity	Wi-Fi 5 or Wi-Fi 6, Bluetooth 4.2
Ports	USB Type-A, USB Type-C, HDMI, headphone/microphone combo jack
