Optical drive
Table 5-1 Optical drive part descriptions and part numbers
Description Spare part number
DVD+/-RW Double-Layer Writer L20485-001
Optical drive bracket L20459-001
Optical drive bezel
Natural silver L20462-001
Pale gold L20463-001
Pale rose gold L57160-001
Iridescent pale rose gold L28514-001
Scarlet red L20467-001
Smoke gray L20465-001
Twilight blue L20464-001
Maroon burgundy L20468-001
Jet black L20461-001
Snow white L20460-001
Iridescent ceramic white L28515-001
Ocean teal L31727-001
Real Tree L31728-001
Berry mauve: Pattern: mesh knit L50308-001
Chalkboard gray: Pattern: mesh knit L50309-001
Jet black; Pattern: mesh knit L50310-001
Lumiere blue; Pattern: mesh knit L50311-001
Snow white; Pattern: mesh knit L50313-001
Before removing the optical drive, follow these steps:
▲ Prepare the computer for disassembly (Preparation for disassembly on page 33).
Remove the optical drive:
1. Remove the Phillips M2.5 × 9.0 screw (1) that secures the drive to the computer.
