Item Component Spare part number
(10) Optical drive connector 747119-001
(11) RTC battery 747132-001
(12) Memory module (PC3L, 12800, 1600-MHz):
8-GB 693374-001
4 GB 691740-001
2 GB 691739-001
(13) Processor (includes replacement thermal materials):
Separate processors only available for models with Intel processors.
Intel Core i5 3230M processor (2.60-GHz, 3.0-MB L3 cache, dual core, 35 W) 711903-002
Intel Core i3 4000M processor (2.40-GHz processor, 3.0-MB L3 cache, dual core, 37 W) 737327-001
Intel Core i3 3110M processor (2.40-GHz, 3.0-MB L3 cache, dual core, 35 W) 682417-001
Intel Pentium 2020M processor (2.40-GHz, 2.0-MB L3 cache) 700628-001
Intel Celeron 1000M processor (1.8-GHz processor, 2.0-MB L3 cache, dual core, 35 W) 713162-001
(14) Hard drive connector 747118-001
(15) Hard drive (SATA; does not include bracket):
NOTE: The hard drive bracket is available using spare part number 747117-001.
1-GB, 5400-rpm, 2.5-in 676521-005
750-GB, 5400-rpm, 2.5-in 634250-005
500-GB, 5400-rpm 669299-005
320-GB, 5400-rpm, 2.5-in (for use only in HP 250 models) 622643-005
(16) Speakers (includes left and right speakers and cable) 747135-001
(17) Battery:
4-cell, 41-Whr, 2.8-Ah Li-ion battery 740715-001
3-cell, 31-Whr, 2.8-Ah Li-ion battery 746641-001
(18) Base enclosure 747112-001
(19) Optical drive (DVD+/-RW Double-Layer SuperMulti) 747125-001
(20) WLAN module:
Atheros AR9485 802.11b/g/n 1x1 WiFi Adapter 675794-001
Ralink RT3290LE 802.11bgn 1x1 Wi-Fi and Bluetooth 4.0 Combo Adapter 690020-001
Atheros AR9565 802.11bgn 1x1 WiFi + BT4.0 combo Adapter 733476-001
Realtek RTL8188EE 802.11bgn Wi-Fi Adapter 709848-001
(21) Service door
NOTE: Included in the Plastics Kit.
747130-001
30 Chapter 3 Illustrated parts catalog
