DVD Solution
DVD SolutionDVD Solution
DVD Solution
The DVD solution for Superdome requires the following components. These components are required per
partition. An external rack AF004A or AF014A must also be ordered with the DVD solution.
NOTE:
NOTE:NOTE:
NOTE:
One DVD is required and one DAT is recommended per nPartition.
NOTE:
NOTE:NOTE:
NOTE:
For OpenVMS, only the one DVD is required per nPartition.
Superdome DVD Solutions
Superdome DVD SolutionsSuperdome DVD Solutions
Superdome DVD Solutions
Description
DescriptionDescription
Description
Part Number
Part NumberPart Number
Part Number
Option Number
Option NumberOption Number
Option Number
PCI 2 channel Ultra320 SCSI (required for OpenVMS)
A7173A
0D1
Surestore Tape Array 5300
C7508BZ
HP DVD+RW Array Module (one per partition)
NOTE:
NOTE: NOTE:
NOTE:
The HP DVD-ROM Array Module for the TA5300
(C7499B) is replaced by HP DVD+RW Array Module (Q1592A) to
provide customers with read capabilities for loading software from
CD or DVD, DVD write capabilities for small amounts of data (up
to 4 GB) and offline hot-swap capabilities. Windows supports using
and reading from this device, but Windows does not support DVD
write with this device. OpenVMS supports reading and booting,
only, from this device, at this time.
Q1592B
0D1
DDS-4/DAT40 (DDS-5/DAT 72 is also supported. Product number
is Q1524B) (one per partition)
C7497C
3
0D1
Jumper SCSI Cable for DDS-4 (optional)
1
C2978B
0D1
SCSI cable 1-meter multi-mode VH-HD68
C2361B
0D1
SCSI Terminator
C2364A
0D1
1
0.5-meter HD HDTS68 is required if DDS-4 or DDS-5 is used.
2
Supported, but may no longer be orderable.
3
Not supported by Linux
Partitions
PartitionsPartitions
Partitions
Superdome can be configured with hardware partitions, (nPars). Superdome systems running Microsoft
Windows Server 2008 for Itanium-based Systems, SUSE Linux Enterprise Server, Red Hat Enterprise Linux,
or OpenVMS, do not support virtual partitions (vPars).
A hardware partition (nPar) consists of one or more cells that communicate coherently over a high
bandwidth, low latency crossbar fabric. Individual processors on a single cell board cannot be separately
partitioned. Hardware partitions are logically and electrically isolated from each other such that
transactions in one partition are not visible to the other hardware partitions within the same complex.
Each nPar runs its own independent operating system. Different nPars may be executing the same or
different revisions of an operating system, or they may be executing different operating systems altogether.
Superdome supports HP UX 11i version 2 and 3, Microsoft Windows Server 2008 for Itanium based
Systems, SUSE SLES 9 ,10 amd 11, Red Hat RHEL AS 3,4 and 5, and OpenVMS operating systems. The
diagram below shows a multi OS environment within Superdome.
NOTE:
NOTE: NOTE:
NOTE:
The sx2000 Superdome with Mad9M processors only supports HP UX 11i version2 and 3 , and
Microsoft Windows Server 2008 for Itanium-based Systems, (does not support any version of Linux or
OpenVMS)
Each nPar has its own independent processors, memory and I/O resources consisting of the resources of
the cells that make up the partition. Resources (cell boards and/or I/O chassis) may be removed from one
nPar and added to another without having to physically manipulate the hardware, but rather by using
QuickSpecs
HP Integrity Superdome Servers 16- processor, 32-
HP Integrity Superdome Servers 16- processor, 32-HP Integrity Superdome Servers 16- processor, 32-
HP Integrity Superdome Servers 16- processor, 32-
processor, and 64- processor Systems
processor, and 64- processor Systemsprocessor, and 64- processor Systems
processor, and 64- processor Systems
Configuration
DA - 11717 Worldwide — Version 57 — October 23, 2009
Page 12
