Multi-cabinet
Multi-cabinetMulti-cabinet
Multi-cabinet
Configurations
ConfigurationsConfigurations
Configurations
When configuring Superdome systems that consist of more then one cabinet and include I/O expansion
cabinets, certain guidelines must be followed, specifically the I/O interface cabling between the
Superdome cabinet and the I/O expansion cabinet can only cross one additional cabinet due to cable
length restrictions.
Configuration Guidelines/Rules
Configuration Guidelines/RulesConfiguration Guidelines/Rules
Configuration Guidelines/Rules
Superdome Configuration Guidelines/Rules
Superdome Configuration Guidelines/RulesSuperdome Configuration Guidelines/Rules
Superdome Configuration Guidelines/Rules
Category
CategoryCategory
Category
Rule Index
Rule IndexRule Index
Rule Index
Rule Description
Rule DescriptionRule Description
Rule Description
General
GeneralGeneral
General
1
Every Superdome complex requires connectivity to a Support Management Station (SMS). The
PC-based SMS also serves as the system console.
2
Every cell in a Superdome complex must be assigned to a valid physical location.
Processor
ProcessorProcessor
Processor
3
All processors in a cell are the same type, same Front Side Bus (FSB) frequency, and same core
frequency.
Memory
MemoryMemory
Memory
4
Configurations with 8, 16 and 32 DIMM slots are recommended (i.e. are fully qualified and
offer the best bandwidth performance.)
5
Configurations with 4 and 24 DIMM slots are supported (i.e. are fully qualified, but don't
necessarily offer the best bandwidth performance).
6
DIMMs can be deallocated in 2 DIMM increments (to support HA).
7
Mixed DIMM sizes within a cell board are supported, but only in separate Mbat interleaving
groups.
8
System orders from the factory provide mixed DIMM sizes in recommended configurations only.
9
For system orders from the factory, the same memory configuration must be used for all cells
within a partition.
10
DIMMs in the same rank must have SDRAMs with the same number of banks and row and
column bits.
11
Size of memory within an interleave group must be power of 2.
12
DIMMs within the same interleave group must be same size and have same number of banks,
row bits, and column bits.
13
There are currently no restrictions on mixing DIMMs (of the same type) with different vendor
SDRAMs.
I/O
I/OI/O
I/O
14
One cell in every partition must be connected to an I/O chassis that contains "Core I/O"
functions. Those require a card connected to boot media, a card connected to removable
media, and a network card with a connected network.
15
A partition cannot have more I/O chassis than it has active cells.
16
Removable media device controller should be in slot 8 of the I/O chassis.
17
Core I/O card must be in slot 0 of the I/O chassis.(sx2000 systems do not have a core I/O)
18
Boot device controller should be in slot 1 of the I/O chassis
19
PCI-X high bandwidth I/O cards should be in the high bandwidth slots in the I/O chassis
20
Every I/O card in an I/O chassis must be assigned to a valid physical location.
21
Every I/O chassis in a Superdome complex must be assigned to a valid physical location
Performance
PerformancePerformance
Performance
22
The amount of memory on a cell should be evenly divisible by 4 GB if using 512-MB DIMMs or
8 GB if using 1-GB DIMMs, i.e. 8, 16 or 32 DIMMs. The cell has four memory subsystems and
each subsystem should have an echelon (2 DIMMs) populated. The loading order of the
QuickSpecs
HP Integrity Superdome Servers 16- processor, 32-
HP Integrity Superdome Servers 16- processor, 32-HP Integrity Superdome Servers 16- processor, 32-
HP Integrity Superdome Servers 16- processor, 32-
processor, and 64- processor Systems
processor, and 64- processor Systemsprocessor, and 64- processor Systems
processor, and 64- processor Systems
Configuration
DA - 11717 Worldwide — Version 57 — October 23, 2009
Page 39
